Overview screen
① Module cover ⑪ Adapter
② Fixing screws module cover ⑫ Transmission ratio selector
③ Fixing screws basic electronics ⑬ Pneumatic block
④ Ribbon cable/connector for fitted potentiom‐
eter or fitted EMC filter module
⑭ Warning label on the side opposite the
nameplate
⑤ Ribbon cable/connector for alarm module,
SIA module or mechanical limit switch mod‐
ule
⑮ SIA module or mechanical limit switch mod‐
ule
⑥ Ribbon cable/connector for position feed‐
back module
⑯ Insulating cover, yellow
⑦ Basic electronics ⑰ Special screw
Installing/mounting
4.5 Installing the optional modules
SIPART PS2 with PROFIBUS PA
54 Operating Instructions, 05/2019, A5E00127926-AC
