NOTICE
Incorrect mounting
The device can be damaged, destroyed, or its functionality impaired through improper
mounting.
● Before installing ensure there is no visible damage to the device.
● Make sure that process connectors are clean, and suitable gaskets and glands are used.
● Mount the device using suitable tools. Refer to the information in Technical data
(Page 281).
4.2 Mounting to linear actuator
Requirements
There are linear actuators for standard mounting in accordance with IEC 60534 and for
integrated mounting. Use the reduced mounting kit 6DR4004-8VK for actuators with integrated
mounting. Integrated mounting is not possible with flameproof stainless steel enclosure
(6DR5..6).
This section describes how to connect the positioner to the linear actuator according to
IEC 60534. Depending on the stroke height, you will need the following mounting kit:
● 3 to 35 mm mounting kit 6DR4004-8V
● 35 to 130 mm mounting kit 6DR4004-8V and additional 6DR4004-8L
See also
Construction (Page 282)
Procedure
"Linear actuator IEC 60534 (3 to 35 mm)" mounting kit 6DR4004-8V and 6DR4004-8L
Sr. no.
*)
Quantity Name Note
① 1 NAMUR mounting bracket
IEC 60534
Standardized connection point for mount with fin, column or plane
surface
② 1 Pick-up bracket Guides the pulley with the carrier pin and rotates the lever arm.
③ 2 Clamping piece Installs the pick-up bracket on the actuator spindle
④ 1 Carrier pin Installation with pulley ⑤ on lever ⑥
⑤ 1 Pulley Installation with carrier pin ④ on lever ⑥
⑥ 1 Lever For the range of stroke from 3 mm to 35 mm
The lever 6DR4004–8L is additionally required for ranges of stroke
> 35 mm to 130 mm (not included in the scope of delivery).
⑦ 2 U–bolts Only for actuators with columns
Installing/mounting
4.2 Mounting to linear actuator
SIPART PS2 with PROFIBUS PA
42 Operating Instructions, 05/2019, A5E00127926-AC
