No. Short de‐
scription
Meaning Representable di‐
agnostics values
Unit Properties
15 DEVI Dynamic control valve behavior 0.0 ... 100.0 % ②
16 ONLK Pneumatic leakage 0.0 ... 100.0 - ②
17 STIC Stiction (slipstick) 0.0 ... 100.0 % ②
18 ZERO Lower endstop 0.0 ... 100.0 % ②
19 OPEN Upper endstop 0.0 ... 100.0 % ②
20 PAVG Average value of position OFF, IdLE, rEF,
COMP
0.0 ... 100.0
% ②
21 P0 Potentiometer value of lower endstop (0%) 0.0 ... 100.0 % ③
22 P100 Potentiometer value of upper endstop (100%) 0.0 ... 100.0 % ③
23 IMPUP Pulse length up 6 ... 160 ms ④
24 IMPDN Pulse length down 6 ... 160 ms ④
25 PAUTP Pulse pause 2 ... 28 ... 320 ms ④
26 DBUP Deadband up 0.1 ... 10.0 % ②
27 DBDN Deadband down 0.1 ... 10.0 % ②
28 SSUP Slow step zone up 0.1 ... 10.0 ...
100.0
% ④
29 SSDN Slow step zone down 0.1 ... 10.0 ...
100.0
% ④
30 TEMP Current temperature -50 ... 100
-58 ... 212
°C
°F
②
31 TMIN Minimum temperature (min/max pointer) -50 ... 100
-58 ... 212
°C
°F
②
32 TMAX Maximum temperature (min/max pointer) -50 ... 100
-58 ... 212
°C
°F
②
33 T1 Number of operating hours in temperature range 1 0 ... 4.29E9 Hours ②
34 T2 Number of operating hours in temperature range 2 0 ... 4.29E9 Hours ②
35 T3 Number of operating hours in temperature range 3 0 ... 4.29E9 Hours ②
36 T4 Number of operating hours in temperature range 4 0 ... 4.29E9 Hours ②
37 T5 Number of operating hours in temperature range 5 0 ... 4.29E9 Hours ②
38 T6 Number of operating hours in temperature range 6 0 ... 4.29E9 Hours ②
39 T7 Number of operating hours in temperature range 7 0 ... 4.29E9 Hours ②
40 T8 Number of operating hours in temperature range 8 0 ... 4.29E9 Hours ②
41 T9 Number of operating hours in temperature range 9 0 ... 4.29E9 Hours ②
42 VENT1 Number of switching cycles of pilot valve 1 0 ... 4.29E9 - ②
43 VENT2 Number of switching cycles of pilot valve 2 0 ... 4.29E9 - ②
44 VEN1R Number of switching cycles of pilot valve 1, resettable 0 ... 4.29E9 - ①
45 VEN2R Number of switching cycles of pilot valve 2, resettable 0 ... 4.29E9 - ①
46 STORE Save the current values as 'last maintenance'
(press button for 5 seconds)
- - ③
47 PRUP Prediction up 1 ... 40 - ④
48 PRDN Prediction down 1 ... 40 - ④
49 WT00 Number of operating hours in the travel range WT00 0 ... 4.29E9 Hours ①
Diagnostics and troubleshooting
12.2 Diagnostics
SIPART PS2 with PROFIBUS PA
258 Operating Instructions, 05/2019, A5E00127926-AC

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
