Basic device without
explosion protection
Basic device with ex‐
plosion protection
Ex d
Basic device with ex‐
plosion protection
Ex "ia"
Basic device with ex‐
plosion protection Ex
"ic", "ec", "t"
● Bus connector with FISCO
supply unit
- - U
i
= 17.5 V
I
i
= 380 mA
P
i
= 5.32 W
"ic":
U
i
= 17.5 V
I
i
= 570 mA
"ec"/"t":
U
n
≤ 32 V
● Bus connector with barrier
U
i
= 24 V
I
i
= 250 mA
P
i
= 1.2 W
"ic":
U
i
= 32 V
"ec"/"t":
U
n
≤ 32 V
Effective inner capacitance C
i
- - Negligible Negligible
Effective inner inductance L
i
- - 8 μH "ic":
8 μH
Current consumption 11.5 mA ± 10 %
Additional fault current 0 mA
Safety shutdown can be activa‐
ted using "Jumper" (terminals
81 and 82)
Electrically isolated from bus circuit and binary input
● Input resistance
> 20 kΩ
● Signal status "0" (shutdown
active)
0 ... 4.5 V or unused
● Signal status "1" (shutdown
inactive)
13 ... 30 V
● For connecting to power
source with the following
peak values
- - U
i
= 30 V
Ii = 100 mA
P
i
= 1 W
"ec":
U
n
≤ 30 V
I
n
≤ 100 mA
"ic":
U
i
= 30 V
I
i
= 100 mA
● Effective internal
capacitance and inductance
- - Negligible Negligible
Binary input BE1
(terminals 9 and 10) electrically
connected to the bus circuit
Jumpered or connection to switch contact.
Suitable only for floating contact; max. contact load
< 5 μA with 3 V
Galvanic isolation
● For basic device without Ex
protection and for basic
device with Ex d
Galvanic isolation between the basic device and the input for safety shutdown and the
outputs of option modules.
● For basic device Ex "ia"
The basic device, the input for safety shutdown, and the outputs of option modules are
individual intrinsically safe circuits.
Technical data
13.7 Electrical specifications
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 287
