3. Tighten the locking screw ② at the flat end of the positioner shaft.


4. Check that the extension shaft sits properly.
5. Screw the 4 threaded bolts ③ into the 4 holes ④.
6. Turn the threaded bolts ③ at least 5 to max. 9 full revolutions into the hole ④.



Booster
E.5 Booster mounting, flameproof enclosure
SIPART PS2 with PROFIBUS PA
342 Operating Instructions, 05/2019, A5E00127926-AC

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
