Booster
● Storage
1K5, but -40 ... +80°C (1K5, but -40 ... +176°F)
● Transport
2K4, but -40 ... +80°C (2K4, but -40 ... +176°F)
Weight booster, single-acting
● Booster, single-acting, polycarbonate, with positioner
4.0 kg (8.8 lb)
● Booster, single-acting, polycarbonate, installation kit only
2.9 kg (6.5 lb)
● Booster, single-acting with flameproof enclosure, with
positioner
7.9 kg (17.4 lb)
● Booster, single-acting with flameproof enclosure,
installation kit only
3.3 kg (7.3 lb)
Weight booster, double-acting
● Polycarbonate enclosure, with positioner
5.3 kg (11.7 lb)
● Polycarbonate enclosure, installation kit only
4.3 kg (9.4 lb)
● Enclosure with flameproof enclosure, with positioner
9.3 kg (20.5 lb)
● Enclosure with flameproof enclosure, installation kit only
4.7 kg (10.4 lb)
Connections
● Pneumatic
1/2-14 NPT or G½
● Manometer
1/4-18 NPT or G1/8
Auxiliary power (air supply) Compressed air, carbon dioxide (CO2), nitrogen (N), noble
gases or cleaned natural gas
● Pressure
1.4 ... 7 bar (20.3 ... 101.5 psi)
● Supply air
According to ISO 8573-1
● Air consumption
1.2 x 10
-2
Nm
3
/h (0.007SCFM)
Manometer Thread 1/4-18 NPT or G½ with stainless steel enclosure
MPa, bar, psi
Degree of protection IP66
Flow capacity Cv 2.0
Booster
E.9 Technical specifications of booster
SIPART PS2 with PROFIBUS PA
350 Operating Instructions, 05/2019, A5E00127926-AC

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
