Siemens SIPART PS2 User Manual

See the notes marked with

to

in the graphic:

Do not apply the cable shield at the positioner 6DR5910-....

Mount the positioner 6DR5910-... to Ground 2 as described under Installing/mounting
(Page 39).
Ground the positioner enclosure as described under Interference immunity (Page 81).

Ground each field distributor. Connect the cable shields only among each other.

Connect the cable shields on the 19" slide-in module to the field distributor.

Ground the 19" slide-in module.

Connect the cable shields to the coupler. Ground the cable shields.
Positioner with remote control electronics
F.6 Grounding concept 19" slide-in module
SIPART PS2 with PROFIBUS PA
362 Operating Instructions, 05/2019, A5E00127926-AC

Siemens SIPART PS2 Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Communication Protocols	HART, PROFIBUS PA, FOUNDATION Fieldbus
Output Pressure	0 to 100% of supply pressure
Hazardous Area Certification	ATEX, IECEx, FM, CSA
Type	Electropneumatic
Input Signal	4-20 mA
Rotation Angle	30° to 90°
Operating Temperature	-40°C to +80°C
Mounting	Linear and rotary actuators
Air Consumption	Typically less than 0.1 kg/h
