Appendix

A.3 I/O Connections and Wiring

FUE1010 IP65 NEMA 4X

176 Operating Instructions, 12/2014, A5E03086491-AC

Table A- 3 Input/Output Wiring (TB3) - 7ME39400AL00 and 7ME39400AL01 I/O Module

Pin#

Signal

Definition

Description

Function

Single

Channel

Function

Dual Channel

Function

Dual Path

Function

Dual Path

Only

1 K1 A Relay 1 Normally

Open

Relay 1 Alarm or

control func-

tions set by

CH 1

Alarm or con-

trol functions

set by CH 1

Alarm or

control func-

tions set by

CH 3

Alarm or con-

trol functions

set by CH 3

2 K1 B Relay 1 Normally

Closed

(7ME39400AL01

only)

K1 C

Relay 1 Common

4 GND Digital Return

[GND]

GND GND GND GND GND

5 K2 A Relay 2 Normally

Open

Relay 2 Alarm or

control func-

tions set by

CH 1

Alarm or con-

trol functions

set by CH 1

Alarm or

control func-

tions set by

CH 3

Alarm or con-

trol functions

set by CH 3

6 K2 B Relay 2 Normally

Closed

(7ME39400AL01

only)

K2 C

Relay 2 Common

8 K3 A Relay 3 Normally

Open

Relay 3 Alarm or

control func-

tions set by

CH 1

Alarm or con-

trol functions

set by CH 2

Alarm or

control func-

tions set by

CH 3

Alarm or con-

trol functions

set by CH 3

9 K3 B Relay 3 Normally

Closed

(7ME39400AL01

only)

K3 C

Relay 3 Common

11 GND Digital Return

[GND]

GND GND GND GND GND

12 K4 A Relay 4 Normally

Open

Relay 4 Alarm or

control func-

tions set by

CH 1

Alarm or con-

trol functions

set by CH 2

Alarm or

control func-

tions set by

CH 3

Alarm or con-

trol functions

set by CH 3.

13 K4 B Relay 4 Normally

Closed

(7ME39400AL01

only)

K4 C

Relay 4 Common
