Siemens SITRANS FUE1010 IP65 NEMA 4X User Manual

Appendix
A.3 I/O Connections and Wiring
FUE1010 IP65 NEMA 4X
Operating Instructions, 12/2014, A5E03086491-AC
181
Note
Re
lays shown in Power OFF position, which is the same as the alarm assertion position.
*7ME39400AL03 Mercury Relay only available with Normally Open.
Table A- 7 Input/Output Wiring (TB4) - 7ME39400AL03 and 7ME39400AL04 Expanded I/O Module
Pin#
Signal
Definition
Description
Single CH
Function
Dual CH
Function
Dual Path
Function
Dual Path
Only
Function
Quad Path
Only
Function
1 AUX I01+ Isolated Loop
Supply Io1
Io1 External
Power
+30V max. supply voltage allowed Not Used
2 AUX I01- Io1 4-20mA Out-
put
Io1 Signal Same output assignment as TB2-9
3 AUX I02+ Isolated Loop
Supply Io2
Io2 External
Power
+30V max. supply voltage allowed
4 AUX I02- Io2 4-20mA Out-
put
Io2 Signal Same output assignment as TB2-11
5 AUX I03+ Isolated Loop
Supply Io3
Io3 External
Power
System outputs assignable and scal-
able to flow related parameters.
4-20mA outputs also provide a fault
indication by dropping to 2mA if as-
signed to flow rate and under fault
conditions.
+30V max. Same as TB2-1
6 AUX I03- Io3 4-20mA Out-
put
Io3 Signal
7 AUX I04+ Isolated Loop
Supply Io4
Io4 External
Power
+30V max. Same as TB2-3
8 AUX I04- Io4 4-20mA Out-
put
Io4 Signal
Note
Auxiliary 4
-20mA loops are assigned and spanned under menu control of Vo and PGEN
out
puts.
