Siemens SITRANS FUE1010 IP65 NEMA 4X User Manual

Appendix
A.3 I/O Connections and Wiring
FUE1010 IP65 NEMA 4X
182 Operating Instructions, 12/2014, A5E03086491-AC
Vc: 24 VDC typical (+15VDC to 30VDC max) Loop Supply
R
L
: 1000 ohms max, = Loop wire resistance plus user's input load resistance
I: 4-20mA
Terminal Block Wiring - 7ME39400AL04 Expanded I/O Module
(Refer to manual drawing 1010N-7-7 sheet 2 of 2)
These connection diagrams apply to the part numbers listed below.
Table A- 8 Connection Diagrams and Part Numbers
1010N-7-7 (Sheet 2 of 2) Drawing
FUH1010
7ME3600, 7ME3603
FUS1010
Not Used
FUE1010
Not Used
