Appendix
A.3 I/O Connections and Wiring
FUE1010 IP65 NEMA 4X
190 Operating Instructions, 12/2014, A5E03086491-AC
Table A- 15 Input/Output Wiring TB1 7ME39404SB00 - Analog Input Module (2 Chan/Dual Path)
Pin
Color
Function
Description
Wiring/Cable
TB1-1
Black
RTD Current High
RTD Temperature measurement T1 or
Channel 1 Ts (Supply Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
TB1-2
White
RTD Voltage High
TB1-3
Green
RTD Voltage Low
TB1-4 Red RTD Current Low
TB1-5
Blue
Ground
Table A- 16 Input/Output Wiring TB2 7ME39404SB00 - Analog Input Module (2 Chan/Dual Path)
Pin
Color
Function
Description
Wiring/Cable
TB2-1
Black
RTD Current High
RTD Temperature measurement T2 or
Channel 1 Tr (Return Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
TB2-2
White
RTD Voltage High
TB2-3
Green
RTD Voltage Low
TB2-4
Red
RTD Current Low
TB2-5
Blue
Ground
Table A- 17 Input/Output Wiring TB3 7ME39404SB00 - Analog Input Module (2 Chan/Dual Path)
Pin
Color
Function
Description
Wiring/Cable
TB3-1
Black
RTD Current High
RTD Temperature measurement T3 or
Channel 2 Ts (Supply Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
TB3-2
White
RTD Voltage High
TB3-3
Green
RTD Voltage Low
TB3-4
Red
RTD Current Low
TB3-5
Blue
Ground
Table A- 18 Input/Output Wiring TB4 7ME39404SB00 - Analog Input Module (2 Chan/Dual Path)
Pin
Color
Function
Description
Wiring/Cable
TB4-1
Black
RTD Current High
RTD Temperature measurement T4 or
Channel 2 Tr (Return Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
TB4-2
White
RTD Voltage High
TB4-3
Green
RTD Voltage Low
TB4-4
Red
RTD Current Low
TB4-5
Blue
Ground
