Siemens SITRANS FUE1010 IP65 NEMA 4X User Manual

Appendix
A.3 I/O Connections and Wiring
FUE1010 IP65 NEMA 4X
Operating Instructions, 12/2014, A5E03086491-AC
193
Table A- 22 Input/Output Wiring TB2 7ME39400SA00 - Analog Input Module
Pin
Color
Function
Description
Wiring/Cable
TB2-1
Black
RTD Current High
RTD Temperature measurement T2 or
Channel 1 Tr (Return Temperature)
AWG. 14 - 24 /
1000 Ft max w/o
factory approval
TB2-2
White
RTD Voltage High
TB2-3
Green
RTD Voltage Low
TB2-4 Red RTD Current Low
TB2-5
Blue
Ground
Table A- 23 Input/Output Wiring TB3 and TB4 7ME39400SA00 - Analog Input Module
Pin
TB3
Function
TB4 Function
Use
Description
Behaviour
Load
Wiring
1
AUX. 1 IN
AUX. 3 IN
Iin1 Input
Analog
current input
referenced
to meter
ground.
4 to 20mA 200Ω 305 meters
(1000 ft.)
Max w/o
factory ap-
proval
2
AUX. 1 COM
AUX. 3 COM
Iin1 Common
3
AUX. 2 IN
AUX. 4 IN
Iin2 Input
4
AUX. 2 COM
AUX. 4 COM
Iin2 Common
Net load is 335 ohms when safety barriers are used.
