Connecting
5.5 Sensor Installation
FUE1010 IP65 NEMA 4X
Operating Instructions, 12/2014, A5E03086491-AC
75
3. Prepare pipe for the track mounts by degreasing the surface, if needed, and removing
any grit, corrosion, rust, loose paint or surface irregularities with the abrasive pipe
conditioning material provided.
4. If this is a horizontal pipe, place the track rail assembly against the pipe. While holding
track, place second track on pipe directly underneath (180°) and hold together in place.
5. Wrap the mounting strap around the pipe and through the strap guide.
Note
For a vertical pipe installation, use a tie, tape or bungee cord to hold the two tracks in
place while mounting.
6. Finger-tighten the chain Tension Screw to secure the strap and tracks to the pipe.
