Scale parameters and functions
8.12 DR 12 Ethernet parameters
SIWAREX WP231
100 Manual, 07/2014, A5E31238908A-02
8.12
DR 12 Ethernet parameters
8.12.1
Overview
Before the SIWAREX module can be integrated into an Ethernet network, the Ethernet
parameters need to be configured.
Table 8- 11 Assignment of data record 12
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record num-
ber
Contains no. of data record USHORT 2 r 12 - - 1500
Length Data record length information USHORT 2 r 116 - - 1501
Application Information about which applica-
tion the DR belongs to
USHORT 2 r 101 - - 1502
Version identifier Information on current data
record version
USHORT 2 r 1 1 65635 1503
Device MAC
address
(Page 102)
Device MAC address 1 USHORT 2 r 0 FF 1504
Device MAC address 2 USHORT 2 r 0 FF 1505
Device MAC address 3 USHORT 2 r 0 FF 1506
Device MAC address 4 USHORT 2 r 0 FF 1507
Device MAC address 5 USHORT 2 r 0 FF 1508
Device MAC address 6 USHORT 2 r 0 FF 1509
Port MAC address
(Page 102)
Port MAC address 1 USHORT 2 r 0 FF 1510
Port MAC address 2 USHORT 2 r 0 FF 1511
Port MAC address 3 USHORT 2 r 0 FF 1512
Port MAC address 4 USHORT 2 r 0 FF 1513
Port MAC address 5 USHORT 2 r 0 FF 1514
Port MAC address 6 USHORT 2 r 0 FF 1515
IP address
(Page 102)
IP address x.n.n.n USHORT 2 r 0 255
IP address n.x.n.n USHORT 2 r 0 255
IP address n.n.x.n USHORT 2 r 0 255
IP address n.n.n.x USHORT 2 r 0 255
Subnet mask
(Page 102)
Subnet mask x.n.n.n USHORT 2 r 0 255
Subnet mask n.x.n.n
USHORT
2
r
0
255
Subnet mask n.n.x.n USHORT 2 r 0 255
Subnet mask n.n.n.x USHORT 2 r 0 255
Gateway Gateway x.n.n.n USHORT 2 r 0 255
Gateway n.x.n.n USHORT 2 r 0 255
Gateway n.n.x.n USHORT 2 r 0 255
Gateway n.n.n.x USHORT 2 r 0 255
Device name
(Page 102)
Current device name header UBYTE[2] 2 rw
Current device name CHAR[32] 32 rw
Reserve 1 Reserve SHORT 2 r
