Scale parameters and functions
8.22 DR 34 ASCII main display value
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
123
8.22
DR 34 ASCII main display value
8.22.1
Overview
The ASCII weight corresponds to the value on the main display of the scales and can be
used for a supplementary display or operating display as well as the legal trade main display.
Reading of the current weight for legal trade use is only possible with the special
SecureDisplay software.
Table 8- 23 Assignment of data record 34
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record
number
Contains no. of data record USHORT 2 r 34 - - 4000
Length Data record length information USHORT 2 r 26 - - 4001
Application Information about which application
the DR belongs to
USHORT 2 r 101 - - 4002
Version iden-
tifier
Information about current data
record version
USHORT 2 r 1 1 65635 4003
ASCII display
string header
Maximum length and actual length
of string
UBYTE[2] 2 r 16.2 - - 4004
Content of
main display
as ASCII
string
(Page 125)
For legal trade display of weight
with increased resolution, ... (see
below)
CHAR[16] 16 r " " - - 4005
