Commissioning
7.7 Service with the SIWATOOL program
SIWAREX WP231
58 Manual, 07/2014, A5E31238908A-02
You can edit all data in the SIWAREX module in online mode. The changes are not
automatically imported to the corresponding scale data block.
To download the data to the SIWAREX module, select the data record with a right mouse
click and send it explicitly to the SIWAREX module.
Online parameter trends can be recorded and played back using the recorder function
located at the top right-hand edge of SIWATOOL. You can use the "Configure recorder"
button to select the data records to be recorded and to set the save parameters. The
playback speed can be set using a slider.
SIWATOOL offers various help options for operation:
● Info card
You can select the "Info" item directly underneath the individual data records in the
navigation tree. This info card explains how the data record influences the scale behavior.
● Tooltip
If you move the mouse over a button or parameter, a corresponding help text is
displayed.
● Help
Click on the menu option "Help" to call up the SIWATOOL help. The Help can be opened
separately.
Entering parameters with SIWATOOL
There is a defined procedure for handling parameters. The current parameters in the
SIWAREX module are displayed in the right-hand window, while the parameter values on the
PC are displayed in the left-hand window. The new parameter value is entered first in the
left-hand window. If several parameters of the data record are to be changed, they are
entered consecutively. The data record is subsequently selected in the tree view and sent to
the SIWAREX modules using the right mouse button.
Parameters are always changed as complete data records, rather than individually.
