Siemens SIWAREX WP231 - DR 9 Module Information; Table 8- 9 Assignment of Data Record 9

Scale parameters and functions
8.10 DR 9 module information
SIWAREX WP231
96 Manual, 07/2014, A5E31238908A-02
8.10
DR 9 module information
No entries can be made in data record DR 9. This data record provides information on the
inner workings of the SIWAREX module. This information is used to identify the module at
the manufacturer plant (e.g. in the event of repairs). The entries in the data record are of no
importance to the user for operation.
Table 8- 9 Assignment of data record 9
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record
number
Contains no. of data
record
USHORT 2 r 9 - - 1340
Length Data record length infor-
mation
USHORT 2 r 68 - - 1341
Application Information on which
application the DR be-
longs to
USHORT 2 r 101 - - 1342
Version identi-
fier
Information on the current
data record version
USHORT 2 r 1 1 65635 1343
Order No. -
header
Maximum and current
string length for the order
number
UBYTE[2] 2 r 16,16 - - 1344
Order No. Order number of the
module
7MH ..
CHAR[16] 16 r "7MH …" - - 1345
Serial number
- header
String header UBYTE[2] 2 r 12,12 - - 1352
Serial number Serial number "
XXX00001"
CHAR[12] 12 r " " - - 1353
Firmware type
- header
String header UBYTE[2] 2 r 2,2 - - 1359
Firmware type Reference V - Release
B - Test
etc.
CHAR[2] 2 r 'V ' - - 1360
Firmware
version - 1st
position
Version 1. USHORT 2 r 0 - - 1361
Firmware
version - 2nd
position
Version 2. USHORT 2 r 0 - - 1362
Firmware
version - 3rd
position
Version 3. USHORT 2 r 0 - - 1363
Hardware
version num-
ber
ES hardware version
number (e.g. 03)
USHORT 2 r 1 - - 1364
OS version
header
String header UBYTE[2] 2 r 1,1 - - 1365
OS version
(loader) -
designation
Reference V - Release
B - Test
etc.
CHAR[2] 2 r 'V ' - - 1366
OS version
(loader) -
designation
e.g. version n USHORT 2 r 'V ' - - 1367
