Scale parameters and functions
8.24 DR 46 protocol contents
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
127
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Delimiters Delimiter (semicolon) CHAR 1 r ";"
Tare Currently effective tare CHAR[8] 8 r " "
String header for
checksum
String header for checksum UBYTE[2] 2 r 4.4
CRC16 checksum Checksum of selected protocol CHAR[4]
4
r "0000" 6146
String header for
date
String header for date UBYTE[2] 2 r 10.10 6147
Date Date CHAR[10] 10 r "2012-03-
31"
6150
String header for
time
String header for time UBYTE[2] 2 r 8.8 6155
Time Time CHAR[8] 8 r "23:59:59" 6156
String header for
supplementary in-
formation
String header for supplementary
information
UBYTE[2] 2 r 2.2 6100
Supplementary info Currently not used CHAR[4] 4 r " " 6161
Reserve Reserve USHORT 2 r 0 6163
1)
The protocol string is read out as a unit over Modbus (Modbus registers 6132 ... 6145)
8.24.2
Oldest protocol ID
The ID of the first saved protocol is displayed here.
8.24.3
Newest protocol ID
The ID of the last saved protocol is displayed here.
8.24.4
Selected protocol ID, numeric
The ID of the protocol requested in data record 45 and shown in data record 46 is displayed
here.
8.24.5
Gross / net identifier
The identifier provides information on whether a gross weight or net weight was logged for
the selected ID.
8.24.6
G/N weight
The G/N weight of the selected log is displayed here.
