Scale parameters and functions
8.5 DR 4 Output of calculated calibration digits
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
81
8.5
DR 4 Output of calculated calibration digits
Data record DR 4 outputs the digits calculated from the automatic scale calibration and the
calibration check. This data record cannot be sent to the scales.
Table 8- 2 Assignment of data record 4
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
Register
Data record num-
ber
Contains no. of the
data record
USHORT 2 r 4 - - 1200
Length Data record length
information
USHORT 2 r 28 - - 1201
Application Information on which
application the DR
belongs to
USHORT 2 r 101 - - 1202
Version identifier Information on
current data record
version
USHORT 2 r 1 1 65635 1203
Calibration digits
0, 1, 2 (calculat-
ed) (Page 81)
Calibration digits 0
(calculated):
calibration digits
calculated by 'auto-
matic calibration'
LONG 4 r 200000 0 1600000 1204
Calibration digits 1
(calculated):
calibration digits
calculated by 'auto-
matic calibration'
LONG 4 r 0 0 1600000 1206
Calibration digits 2
(calculated):
calibration digits
calculated by 'auto-
matic calibration'
LONG 4 r 0 0 1600000 1208
Reserve 1 Reserve SHORT 2 r 0 - - 1210
Reserve 2 Reserve USHORT 2 r 0 - - 1211
Reserve 3 Reserve FLOAT 4 r 0 - - 1212
8.5.1
Calibration digits 0, 1, 2 (calculated)
The calculation is based on the parameters from DR 10 and is executed using command no.
82 or 83.
