Scale parameters and functions
8.15 DR 15 tare settings
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
107
8.15
DR 15 tare settings
8.15.1
Overview
Data record DR 15 is used for the external specification of up to 3 tare weights.
Procedure
● Enter the tare weight(s)
● Transfer the data record to the scales
● Enable a tare weight with a command
Table 8- 16 Assignment of data record 15
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record
number
Contains no.
of data rec-
ord
USHORT 2 r 15 - - 1578
Length Data record
length infor-
mation
USHORT 2 r 28 - - 1579
Application Information
about which
application
the DR
belongs to
USHORT 2 r 101 - - 1580
Version
identifier
Information
on current
data record
version
USHORT 2 r 1 1 65635 1581
Specification
of tare weight
1, 2, 3
(Page 108)
Tare setting
memory 1
FLOAT 4 rw 0 0 Depends on
specification
in DR 3
1582
Tare setting
memory 2
FLOAT 4 rw 0 0 Depends on
specification
in DR 3
1584
Tare setting
memory 3
FLOAT 4 rw 0 0 Depends on
specification
in DR 3
1586
Reserve 1 Reserve SHORT 2 rw 0 0 - 1588
Reserve 2 Reserve USHORT 2 rw 0 0 - 1589
Reserve 3 Reserve FLOAT 4 rw 0 0 - 1590
8.15.2
Specification of tare weight 1, 2, 3
Up to three tare weights can be entered. If a tare weight is to be applied, it must be enabled
with the corresponding command. The tare weights may not exceed the maximum values
specified in data record DR 3.
