Scale parameters and functions
8.20 DR 31 advanced current process values
SIWAREX WP231
118 Manual, 07/2014, A5E31238908A-02
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Current
status of
digital output
0, 1, 2, 3
(Page 120)
Current status of output 0 BIT 0 r 0 0 1 3312.8
Current status of output 1 BIT 0 r 0 0 1 3312.7
Current status of output 2 BIT 0 r 0 0 1 3312.6
Current status of output 3 BIT 0 r 0 0 1 3312.5
Reserve BIT 0 r 0 0 1 3312.4
Reserve BIT 0 r 0 0 1 3312.3
Reserve BIT 0 r 0 0 1 3312.2
Reserve BIT 2 r 0 0 1 3312.1
Refresh
counter for
process
values
(Page 120)
Refresh counter incremented by 1
if weight values were changed
USHORT 2 r 0 - - 3313
Current load
cell signal in
mV
(Page 120)
Currently measured load cell
signal
FLOAT 4 r 0 - - 3314
8.20.2
Unfiltered digit value
The unfiltered digit value is the internal measured value immediately before filtering.
8.20.3
Filtered digit value
The filtered digit value is the internal measured value immediately after filtering.
8.20.4
Filtered digit value (commissioning aid)
The filtered digit value is the internal measured value immediately after filtering with the
commissioning filter.
8.20.5
Digits for analog output
The current digit value for the digital-to-analog converter for the analog output. The
resolution of the analog output is 16 bit.
8.20.6
Current status of input 0, 1, 2, 3
This parameter allows you to check the current status of the digital inputs.
