Siemens SIWAREX WP231 - DR 6 Limit Value Settings

Scale parameters and functions
8.7 DR 6 limit value settings
SIWAREX WP231
84 Manual, 07/2014, A5E31238908A-02
8.7
DR 6 limit value settings
The switch-on and switch-off values for the limits are configured in data record DR 6.
In legal trade operation, the data record is not write-protected.
Procedure
● Check all parameters and modify them as required
● Transfer the data record to the scales
Table 8- 4 Assignment of data record 6
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
Register
Data record
number
Contains no. of data
record
USHORT 2 r 6 - - 1234
Length Data record length infor-
mation
USHORT 2 r 60 - - 1235
Application Information about which
application the DR be-
longs to
USHORT 2 r 101 - - 1236
Version iden-
tifier
Information about the
current data record ver-
sion
USHORT 2 r 1 1 65635 1237
Basis of limits Gross / net basis of limit
values 1 and 2
0: Limit value 1 and limit
value 2 are based on the
gross value
1: Limit value 1 and limit
value 2 are based on the
net value
USHORT 2 rw 0 0 1 1238
Reserve 1 Reserve USHORT 2 rw 0 0 - 1239
Limit value 1
ON, limit
value 2 ON,
limit value 1
OFF, limit
value 2 OFF
(Page 86)
Switch-on point for limit
value 1 (% of measuring
range)
FLOAT 4 rw 0 maxi-
mum
num-
ber
range
maxi-
mum
number
range
1240
Delay time for
limit value 1
ON, delay
time for limit
value 2 ON
(Page 86)
Time for delayed switch-
on of limit value 1 in ms
TIME 4 rw 0 0 maxi-
mum
number
range+
1242
Limit value 1
ON, limit
value 2 ON,
limit value 1
OFF, limit
value 2 OFF
(Page 86)
Switch-off point for limit
value 1 (% of measuring
range)
FLOAT 4 rw 0 maxi-
mum
num-
ber
range
maxi-
mum
number
range
1244
