Siemens SIWAREX WP231 - DR 14 SIMATIC Interface Parameters; Overview

Scale parameters and functions
8.14 DR 14 SIMATIC interface parameters
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
105
8.14
DR 14 SIMATIC interface parameters
8.14.1
Overview
The parameters which define the response of the SIMATIC interface are specified in data
record DR 14. It is possible to define the process values to be output on the basis of the I/O
area.
Procedure
● Check the parameters and modify them as required
● Transfer the data record to the scales
Table 8- 13 Assignment of data record 14
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Data record
number
Contains no.
of data rec-
ord
USHORT 2 r 14 - - 1570
Length Data record
length infor-
mation
USHORT 2 r 16 - - 1571
Application Information
about which
application
the DR
belongs to
USHORT 2 r 101 - - 1572
Version
identifier
Information
on current
data record
version
USHORT 2 r 1 1 65635 1573
Selection of
process
value 1, 2
(Page 107)
Selection of
process
value 1 (S7
I/O inter-
face): Code
for selection
of process
variable to be
updated
USHORT 2 rw 4 0 10 1574
Selection of
process
value 2 (S7
I/O inter-
face): Code
for selection
of process
variable to be
updated
USHORT 2 rw 6 0 10 1575
Reserve 1 Reserve SHORT 2 rw 0 0 - 1576
Reserve 2 Reserve USHORT 2 rw 0 0 - 1577
