Scale parameters and functions
8.3 DR 3 calibration parameters
SIWAREX WP231
68 Manual, 07/2014, A5E31238908A-02
Variable
Note
Type
Length
(bytes)
Read/write
protection
Default
Min.
Max.
Modbus
registers
Reserve Reserve UBYTE[2] 2 rw 0 - - 1082
Reserve Reserve CHAR[20] 20 rw 0 - - 1083
Minimum
display size
[%]
(Page 76)
Maximum factor for minimizing
the SecureDisplay. Value must
not be smaller than the smallest
value defined in the DisplayCali
file.
USHORT 2 rwP 0 - - 1093
Reserve 4 Reserve FLOAT 4 rw 0 - - 1094
1)
Parameter for calculation of calibration points with theoretical calibration
8.3.2
Scale name
You can select any name, but it may not exceed 12 characters. You can enter any
designation.
Note
The scale name cannot be changed after official verification.
8.3.3
Unit of weight
A string with up to four digits can be specified as the unit of weight, e.g.: t, kg, lbs. The
defined unit of weight applies to all weight specifications. Entries are not be converted if the
unit of weight has changed. Entries must be left-aligned.
8.3.4
Gross identifier
The gross identifier specifies the letter, B (for brutto) or G (for gross), to be used in the
display for gross weights.
8.3.5
Code for regulations
Trade scales requiring official calibration are subject to certain restrictions. The restrictions in
accordance with the OIML directive are activated by entering "1" for OIML R76. Enter "0" to
deactivate the restrictions (function available soon).
