Scale parameters and functions
8.22 DR 34 ASCII main display value
SIWAREX WP231
124 Manual, 07/2014, A5E31238908A-02
8.22.2
Content of main display as ASCII string
The following values can be displayed in non-automatic weighing instruments (NAWI)
applications:
Gross process value From DR 30
Net process value From DR 30
G/N weight From DR 0
G/N weight x10 From DR 30
Tare From DR 30
Gross_2 process value From DR 30
Firmware version From DR 9
Current calibration regulation From DR 9
Serial number of module From DR 9
Below are some display examples. Commands are used to toggle display values.
The values to be displayed are hidden if, for example, a fault is pending or a value is outside
the valid display range.
Value designation
Blank
Display value
Unit of weight
(from DR 3)
Weight
(Tare ≠ 0)
NET • • • • • 2 2 0 . 5 0 •kg•
Weight
(Tare = 0)
B • • • • • • - 0 . 0 3 •t••
Operator error • • • • • • 1 0 . 0 0 3 HIGH
Weight simulation activated B • • • • • • E r r o r TEST
Max+9e exceeded B • • • • • • - 0 . 0 3 ****
Tare display activated (pt)
p
T
•
1
2
5
6
7
8
.
9
0
•kg•
Tare display activated T • • • • • • 5 0 . 5 0 •kg•
NET = net
B = gross
T = tare
pT = preset tare (tare setting active)
S = sum
