Scale parameters and functions
8.13 DR 13 RS485 parameters
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
103
Variable
Note
Type
Length
(bytes)
Rw
Default
Min.
Max.
Modbus
registers
Bit 10 Reserve BIT 0 rw 0 0 1 1564.6
Bit 11 Reserve BIT 0 rw 0 0 1 1564.5
Bit 12 Reserve BIT 0 rw 0 0 1 1564.4
Bit 13 Reserve BIT 0 rw 0 0 1 1564.3
Bit 14 Reserve BIT 0 rw 0 0 1 1564.2
Bit 15 Reserve BIT 2 rw 0 0 1 1564.1
RS485 Mod-
bus address
(Page 105)
MODBUS address for Vito mod-
ule
USHORT 2 rw 20 1 255 1565
Decimal
place for
Siebert
indicator
(Page 105)
Decimal place for Siebert display SHORT 2 rw 0 - - 1566
MODBUS
RTU frame
delay
Delay time for response with
MODBUS RTU in ms (RS485)
USHORT 2 rw 0 - - 1567
Reserve 3 Reserve FLOAT 4 rw 0 - - 1568
8.13.2
RS485 protocol
This parameter defines the protocol for communication via the RS485 interface.
Value
Protocol
0 No communication/protocol
1 Modbus RTU
2 SIEBERT display
8.13.3
RS485 baud rate
This parameter defines the baud rate for the RS485 interface.
Value
Baud rate
0 1 200 bps
1 2 400 bps
2 9 600 bps
3 19 200 bps
4 38 400 bps
5 57 600 bps
6 115 000 bps
