Scale parameters and functions
8.8 DR 7 interface parameters
SIWAREX WP231
88 Manual, 07/2014, A5E31238908A-02
8.8
DR 7 interface parameters
Data record DR 7 contains the parameters for defining the properties of the available I/O
modules (digital inputs, digital outputs, analog output, serial ports).
If a port is not used, the default values can be retained.
Procedure
Change the parameters if necessary
Transfer the data record to the scales
Table 8- 5 Assignment of data record 7
Variable
Note
Type
Length
(bytes)
RW
Default
Min.
Max.
Modbus
Register
Data record
number
Contains no. of data record USHORT 2 r 7 - - 1300
Length Data record length infor-
mation
USHORT 2 r 60 - - 1301
Application Information about which
application the DR belongs
to
USHORT 2 r 101 - - 1302
Version identifier Information about the current
data record version
USHORT 2 r 1 1 65635 1303
Assignment for
digital input 0, 1,
2, 3 (Page 92)
Assignment for input 0:
Code 0: No command as-
signed
1 … 32767: Command is
triggered at a rising edge (0-
>1 transition)
USHORT 2 rw 0 0 1999 1304
Assignment for input 1:
Code 0: No command as-
signed
1 … 32767: Command is
triggered at a rising edge (0-
>1 transition)
USHORT 2 rw 0 0 1999 1305
Assignment for input 2:
Code 0: No command as-
signed
1 … 32767: Command is
triggered at a rising edge (0-
>1 transition)
USHORT 2 rw 0 0 1999 1306
Assignment for input 3:
Code 0: No command as-
signed
1 … 32767: Command is
triggered at a rising edge (0-
>1 transition)
USHORT 2 rw 0 0 1999 1307
Input filtering
(hardware set-
ting) (Page 92)
0: 0.2 ms
1: 0.2 ms
2: 0.4 ms
3: 0.8 ms
4: 1.6 ms
5: 3.2 ms
6: 6.4 ms
7: 12.8 ms
USHORT 2 rw 5 0 7 1308
