Scale parameters and functions
8.8 DR 7 interface parameters
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
89
Variable
Note
Type
Length
(bytes)
RW
Default
Min.
Max.
Modbus
Register
Assignment for
digital output 0,
1, 2, 3 (Page 92)
Assignment for output 0:
Code 0 … 0x1F hex: Bit no.
of the status flags from byte
0 to 3 (DR 30)
Code 0x21 hex: Data record
18
Code 0x22 hex: S7 I/O
modules
Code 0xFF hex: Output
always disabled
USHORT 2 rw 0 0 0xFFFF 1309
Assignment for output 1:
(see output 0)
USHORT 2 rw 0 0 0xFFFF 1310
Assignment for output 2:
(see output 0)
USHORT 2 rw 0 0 0xFFFF 1311
Assignment for output 3:
(see output 0)
USHORT 2 rw 0 0 0xFFFF 1312
Response of
digital outputs to
faults or
SIMATIC STOP
(Page 93)
Response of digital outputs
following module fault or
CPU STOP:
0: Outputs are switched off
1: Outputs are not switched
off, continue
2: The relevant substitute
value is activated
3: The outputs are switched
on
USHORT 2 rw 0 0 0 1313
Substitute value
for DQ 0, 1, 2, 3
following fault or
SIMATIC STOP
(Page 93)
Substitute value for DQ 1
following fault or SIMATIC
CPU STOP
BIT 0 rw 0 0 1 1314.16
Substitute value for DQ 2
following fault or SIMATIC
CPU STOP
BIT 0 rw 0 0 1 1314.15
Substitute value for DQ 3
following fault or SIMATIC
CPU STOP
BIT 0 rw 0 0 1 1314.14
Substitute value for DQ 4
following fault or SIMATIC
CPU STOP
BIT 0 rw 0 0 1 1314.13
Bit 4 Reserve BIT 0 rw 0 0 1 1314.12
Bit 5 Reserve BIT 0 rw 0 0 1 1314.11
Bit 6 Reserve BIT 0 rw 0 0 1 1314.10
Bit 7 Reserve BIT 0 rw 0 0 1 1314.9
Bit 8 Reserve BIT 0 rw 0 0 1 1314.8
Bit 9 Reserve BIT 0 rw 0 0 1 1314.7
Bit 10 Reserve BIT 0 rw 0 0 1 1314.6
Bit 11 Reserve BIT 0 rw 0 0 1 1314.5
Bit 12 Reserve BIT 0 rw 0 0 1 1314.4
Bit 13 Reserve BIT 0 rw 0 0 1 1314.3
Bit 14 Reserve BIT 0 rw 0 0 1 1314.2
Bit 15 Reserve BIT 2 rw 0 0 1 1314.1
Analog output
range (Page 94)
0: 0 … 20 mA
1: 4 … 20 mA
USHORT 2 rw 0 0 1 1315
