Scale parameters and functions
8.8 DR 7 interface parameters
SIWAREX WP231
90 Manual, 07/2014, A5E31238908A-02
Analog output
source
(Page 94)
Basis of analog value output:
0 = G/N value
1 = Gross
2 = Net
3 = Ext. specification, DR 17
4 = Ext. specification, S7
interface
USHORT 2 rw 2 0 3 1316
Response of
analog output to
faults or
SIMATIC STOP
(Page 94)
0: Switch off
1: Continue
2: Output configured output
value
3: Output maximum value
(24 mA, NAMUR)
USHORT 2 rw 0 0 3 1317
Start value for
the analog
output (Page 94)
Value at which 0 …4 mA is
to be output
FLOAT 4 rw 0 maximum
weighing
range
maxi-
mum
weigh-
ing
range
1318
End value for
the analog
output (Page 94)
Value at which 20 mA is to
be output
FLOAT 4 rw 0 maximum
weighing
range
maxi-
mum
weigh-
ing
range
1320
Output value
following fault or
SIMATIC STOP
(Page 95)
Value to be output when the
OutDis signal is enabled (in
mA)
FLOAT 4 rw 0 0 24 1322
Trace recording
cycle (Page 95)
1: 10 ms
10: 100 ms
100: 1 s
1 000: 10 s
USHORT 2 rw 1 1 1000 1324
Trace storage
method, bit 0
0: Trace recording runs as a
circular buffer
1: Trace is stopped when the
trace memory is full
BIT 0 rw 0 0 1 1325.16
Bit 1 Reserve BIT 0 rw 0 0 1 1325.15
Bit 2 Reserve BIT 0 rw 0 0 1 1325.14
Bit 3 Reserve BIT 0 rw 0 0 1 1325.13
Bit 4 Reserve BIT 0 rw 0 0 1 1325.12
Bit 5 Reserve BIT 0 rw 0 0 1 1325.11
Bit 6 Reserve BIT 0 rw 0 0 1 1325.10
Bit 7 Reserve BIT 1 rw 0 0 1 1325.9
Bit 8 Reserve BIT 0 rw 0 0 1 1325.8
Bit 9 Reserve BIT 0 rw 0 0 1 1325.7
Bit 10 Reserve BIT 0 rw 0 0 1 1325.6
Bit 11 Reserve BIT 0 rw 0 0 1 1325.5
Bit 12 Reserve BIT 0 rw 0 0 1 1325.4
Bit 13 Reserve BIT 0 rw 0 0 1 1325.3
Bit 14 Reserve BIT 0 rw 0 0 1 1325.2
Bit 15 Reserve BIT 1 rw 0 0 1 1325.1
Reserve 1 Reserve LONG 4 rw 0 0 - 1326
Reserve 2 Reserve FLOAT 4 rw 0 0 - 1328
