Scale parameters and functions
8.8 DR 7 interface parameters
SIWAREX WP231
94 Manual, 07/2014, A5E31238908A-02
8.8.11
Output value following fault or SIMATIC STOP
The default settings set the analog output to the defined value following a module fault
(operating error) or upon SIMATIC CPU STOP.
If the analog output is, for example, to be set to 3.5 mA following a fault, this is defined with
this parameter. The current value to be output is entered.
NOTICE
System can be switched to unsafe state
If the analog output is to be set to a given value following a fault (operating error), you must
ensure that this poses no danger.
8.8.12
Trace recording cycle
The trace function is used for the continuous recording of measured values. The recording
rate is defined with the parameter.
Value
Response
1 Recording every 10 ms
10 Recording every 100 ms
100 Recording every second
1 000 Recording every 10 s
8.8.13
Trace storage method
This parameter is used to specify the response of the trace memory.
Value
Response
0 Trace recording runs as circulating memory
1 Trace is stopped when the trace memory is full
