Scale parameters and functions
8.21 DR 32 display of data and operator errors
SIWAREX WP231
Manual, 07/2014, A5E31238908A-02
121
6002 Recording not possible because weight
iinvalid
BIT r 0 0 1 3505.5
7000 Permitted number range violated BIT r 0 0 1 3506.16
BIT r 0 0 1 3506.15
7001 Regulation code unknown BIT r 0 0 1 3506.14
7002 Specifications of string lengths not plausi-
ble
BIT r 0 0 1 3506.13
7003 Specification of date / time not plausible BIT r 0 0 1 3506.12
7004 Assignment of digital inputs/outputs incor-
rect
BIT r 0 0 1 3506.11
7006 Command only possible in test field BIT r 0 0 1 3506.10
7007 The calibration weights or calibration
digits are not plausible
BIT r 0 0 1 3506.9
7008 Zeroing/zero setting or tare parameter not
plausible
BIT r 0 0 1 3506.8
7009 Standstill range / standstill wait time not
plausible
BIT r 0 0 1 3506.7
7010 Scale interval / rounding not plausible BIT r 0 0 1 3506.6
Filter parameter not plausible
7013 Interface assignment for verifiable HMI
not plausible
BIT r 0 0 1 3506.4
Reserve - BIT r 0 0 1 3506.3
Reserve - BIT r 0 0 1 3506.2
7016 Parameter assignment of analog output
not plausible
BIT r 0 0 1 3506.1
7017 MAC address cannot be changed BIT r 0 0 1 3607.16
7019 RS485 parameter error BIT r 0 0 1 3607.14
Reserve - USHORT 2 r 0 - - 3504
Reserve - USHORT 2 r 0 - - 3505
Reserve - USHORT 2 r 0 - - 3506
Reserve - USHORT 2 r 0 - - 3507
Reserve - USHORT 2 r 0 - - 3508
Modbus RTU
error code
(Page 123)
Synchronous error code for communica-
tion at the Modbus RS485 interface
USHORT 2 r 0 - - 3509
Modbus
Ethernet error
code
(Page 123)
Synchronous error code for communica-
tion at the Modbus Ethernet interface
USHORT 2 r 0 - - 3510
SIWATOOL
error code
(Page 123)
Synchronous error code for communica-
tion at the SIWATOOL interface
USHORT 2 r 0 - - 3511
Error code
following
commands at
digital input
(Page 123)
Synchronous error code caused by com-
mand at the DI
USHORT 2 r 0 - - 3512
Reserve - USHORT 2 r 0 - - 3513
