Page 8 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
8. Make certain that all system wiring is terminated at specified terminal locations as
specified in the Simplex Field Wiring Diagram (Part No. 841-731).
9. Perform a complete system test of all installed devices.
10. Install the retainer panel on the back box with the retainer clips at the top of the
back box (See Figure 6).
