Section 09 TECHNICAL DATA
Sub-Section 04 (TECHNICAL DATA LEGENDS)
09-04-1
ENGINE TECHNICAL DATA
LEGEND
BP : Breaker Points
BTDC :Before Top Dead Center
CDI : Capacitor Discharge Ignition
CTR : Center
K : Kilo (x 1000)
MAG : Magneto Side
N.A. : Not Applicable
PTO : Power Take Off Side
R : Rectangular
ST : Semi-trapez
µ : Micro (÷ 1 000 000)
➀ The maximum horsepower RPM is applicable
on the vehicle. It may be different under certain
circumstances and BOMBARDIER INC. re-
serves the right to modify it without obligation.
➁ Rotary valve to crankcase clearance : 0.27 –
0.48 mm (.011 – .019 in).
➂ At 6000 RPM (engine cold) with headlamp
turned on.
➃ Force applied midway between pulleys to ob-
tain specified deflection.
➄ Crankshaft end-play is not adjustable on these
models except Tundra II LT. Specification is giv-
en for verification purposes only.
➅ Drive pulley retaining screw : torque to 90 to
100 N•m (66 to 74 lbf•ft), install drive belt, ac-
celerate the vehicle at low speed (maximum 30
km/h (20 MPH)) and apply the brake ; repeat 5
times. Recheck the torque of 90 to 100 N•m
(66 to 74 lbf•ft).
➆ All resistance measurements must be per-
formed with parts at room temperature (ap-
prox. 20°C (68°F)). Temperature greatly affects
resistance measurements.
VEHICLE TECHNICAL DATA
LEGEND
DSA : Direct Shock Action
RRIM : Reinforced Reaction Injection Molding
TRA : Total Range Adjustable drive pulley
N.A. : Not Applicable
➀ Minimum allowable width may not be less than
3.0 mm (1/8 in) of new drive belt.
➁ Force applied midway between pulleys to ob-
tain specified deflection.
➂ Force or downward pull applied to track to ob-
tain specified tension deflection.
➃ Lever with roller pin P/N 417 0043 03 (Hollow).
➄ 2C : 2 Caps
1W : 1 Washer
