Ski-Doo FORMULA SL 1997 User Manual

Section 05 ELECTRICAL
Sub-Section 05 (TESTING PROCEDURE)
05-05-10
INSPECTION OF HEATING ELEMENTS
All measurements must be performed at 21°C (70°F).
Throttle Lever Heating Element
Resistance Measurement
Current Measurement
Handlebar Grip Heating Element
Resistance Measurement
➀
When measuring resistance at terminals the actual
value will be half the measurement in table. The
reason for that is the elements are connected in
parallel. Therefore the total resistance is half the
resistance of one element.
HIGH
INTENSITY
YELLOW
/
BLACK wire
BROWN wire
1.96 to
3.64 ohms
LOW
INTENSITY
YELLOW
/
BLACK wire
BROWN
/
YELLOW wire
8.05 to
14.95 ohms
HIGH
INTENSITY
BROWN wire
0.23 Amp.
minimum
LOW
INTENSITY
BROWN
/
YELLOW wire
0.13 Amp.
minimum
HIGH
INTENSITY
YELLOW
/
BLACK wire
ORANGE wire
8.73 to
➀
10.67 ohms
LOW
INTENSITY
YELLOW
/
BLACK wire
ORANGE
/
VIOLET wire
17.7 to
➀
20.7 ohms
