Section 08 BODY/FRAME

Sub-Section 02 (BODY)

08-02-5

REPAIR

The very first step before repairing plastic materials is to find out exactly which type of material is in-

volved. Refer to following chart.

CAUTION

Consult chart and repair kit instructions carefully, some repair products are not compatible with

certain plastics.

◆

WARNING

Polycarbonate windshields must never be repaired by welding or otherwise.

REPAIRABLE

PART MODEL FIBERGLASS

R.I.M.

URETHANE

POLYETHYLENE

HOOD Skandic

WT/SWT/WT LC

S-Series

A06H194

BOTTOM PAN Skandic

WT/SWT/WT LC

S-Series

A06H1A4

SIDE PANEL AND

REAR MOLDING

S-Series

A06H1B4
