Section 05 ELECTRICAL
Sub-Section 05 (BATTERY)
05-05-2
1. Wing screw
Skandic SWT
Remove battery bracket and remove battery from
vehicle.
Skandic WT LC
Unscrew wing screw and remove bracket with
solenoid.
Remove battery cover and remove battery from
vehicle.
1. Wing screw
All Models
Withdraw battery from vehicle being careful not
lean it so that electrolyte flows out of vent tube.
CLEANING
Clean the battery, battery casing, vent tube, caps,
cables and battery posts using a solution of baking
soda and water.
A22E0GA
1
A29E0DA
-
CAUTION
Should any electrolyte spillage occur, imme-
diately wash off with a solution of baking
soda and water to prevent damage to vehi-
cle components.
-
CAUTION
Do not allow cleaning solution to enter bat-
tery interior since it will destroy the electro-
lyte.
A29E0CA
1
