Section 04 TRANSMISSION

Sub-Section 08 (DRIVE CHAIN)

04-08-1

DRIVE CHAIN 0

SILENT CHAIN

For 1997 there are 2 types of silent chain. One is

11-plate wide and the other (stronger) is 13-plate

wide. Do not interchange sprockets. Fit chain on

sprockets to make sure using right ones accord-

ing to width. Refer to TECHNICAL DATA 09-03.

NOTE:

No work (separation, lengthening) can be

done on the silent chain type.
