Ski-Doo FORMULA SL 1997 User Manual

Section 05 ELECTRICAL
Sub-Section 07 (TESTING PROCEDURE)
05-07-8
SUMMARY TABLE
Test to perform
Tester
wires
Components wires Switch Dial
Trigger coil output
N
BLUE/YELLOW
wire of
trigger coil
LOW 15
P
WHITE/YELLOW
wire of
trigger coil
Ignition coil output N Engine ground
LOW 45
P
Test adapter
on MAG
spark plug cable
Ignition module output
N
WHITE/BLUE
wire (+)
of ignition coil
LOW 85
P
BLACK
wire (−)
of ignition coil
Magneto output
(ignition generator coil) N
RED
wire of
magneto harness
LOW 85
P
BLACK/RED
wire of
magneto harness
Lighting generator coil
output N
YELLOW
wire of
magneto harness
LOW 75
P
YELLOW
wire of
magneto harness
