Section 02 TROUBLESHOOTING
Sub-Section 04 (TRANSMISSION AND BRAKE SYSTEMS)
02-04-1
TRANSMISSION AND BRAKE
SYSTEMS 4
The following charts are provided to help in diagnosing the probable source of troubles. It should be used
as a guideline. Some causes or corrections may not apply to a specific model.
TRANSMISSION
SYMPTOM THE SNOWMOBILE ACCELERATES SLOWLY, ESPECIALLY WHEN IT IS STOPPED
CONDITION NORMAL USE
Test/Inspection 1. Check drive belt condition.
a.Belt is too narrow (drive belt engagement is higher in drive pulley).
Replace belt if width is 3 mm (1/8”) less than a new one (refer to TECHNICAL
DATA 09).
2. Check distance between pulleys and/or drive belt deflection.
a.Distance is too small between pulleys or deflection is too high (drive belt engagement
is higher in drive pulley).
Adjust distance between pulleys and/or drive belt deflection according to specifications
(refer to TECHNICAL DATA 09).
3. Check driven pulley sliding half play.
a.Jammed sliding half.
Replace.
4. Check spring tension of driven pulley sliding half.
a.Sliding half rotation is accelerated when spring tension is too weak.
Adjust according to specifications (refer to TECHNICAL DATA 09).
5. Refer to “Vibrations originating from driven pulley” and check items listed.
6. Check drive pulley spring tension.
a.Spring tension is too weak.
Replace.
