Section 05 ELECTRICAL

Sub-Section 04 (SPARK PLUGS)

05-04-1

SPARK PLUGS 4

NGK SPARK PLUG

All Models

NGK SPARK PLUG NUMBERING

SYSTEM

Bombardier is using the NGK spark plug type on

most of the 1997 snowmobile models.

The heat range identification system is:

High number hot plug

Low number cold plug

1997 REFERENCE CHART

NGK spark plugs used on 1997 Bombardier snow-

mobiles covered in this manual:

–BR8ES

–BR9ES
