205
SJ63 AJ+, SJ63 AJ 229043AAA
Platform Section 5 – Procedures
P11 (Black) Slave Controller: SMB1-106
Pin Wire Function Input/Output Type I/O Name Label
1 04 Power VS1
2 04 Power VS2
3 04 Power VS3
4 04 Power VS4
5 L Speed control supply (T Booms) Vreg 5v
6 Not Used J1939 CAN
7 Not Used J1939 CAN
8 CAN 2H CANH To PLTF SMB1-106 CANopen
9 CAN 2L CANL To PLTF SMB1-106 CANopen
10 02 Ground GND1
11 02 Ground GND2
12 02 Ground GND3
13 02 Ground GND4
14 Not used --
