Skyjack SJ63 AJ+ Service Manual

206
SJ63 AJ+, SJ63 AJ229043AAA
Section 5 – Procedures Platform
P12 (Grey) Slave Controller: SMB1-106
Pin Wire Function Input/Output Type I/O Name Label
1 37 Platform Rotation Right PWM01 PWM17
2 36 Platform Rotation Left PWM00 PWM16
3 Not Used PWM07 PWM23
4 Not Used PWM06 PWM22
5 Not Used PWM05 PWM21
6 Not Used PWM04 PWM20
7 Not Used PWM11 DEPOP
8 Not Used PWM10 DEPOP
9 Not Used PWM09 DEPOP
10 Not Used PWM08 DEPOP
11 Not Used -- --
12 Not Used PWM14 DEPOP
13 35 Jib Up PWM02 PWM18
14 08A Footswitch Actuated Y P4B DIN28
15 24P Steer Left Y P72 DIN30
16 23P Steer Right Y P77 DIN32
17 45 High Torque Drive Mode Selected Y P7C DIN34
18 01 Emergency Pump Request Y PF0 DIN36
19 04A Engine Run/Enable P25 DIN38
20 MPS2 = KC O/H (Korea) Y P82 DIN40
21 38A Fly Boom In Y P92 DIN42
22 41A Platform Level Up Y PC0 DIN44
23 Not Used PWM13 DEPOP
24 34 Jib Down PWM03 PWM19
25 233 Glazier Load Restrict P49 DIN27
26 34A Jib Down Y P4D DIN29
27 Not Used Y P74 DIN31
28 35A Jib Up Y P7A DIN33
29 78 High Throttle Selected Y P7E DIN35
30 57B Engine Start Request Y PF2 DIN37
31 MPS1 = KC O/H (Korea) Y P20 DIN39
32 11A Propane Fuel Select P90 DIN41
33 39A Fly Boom Out Y P94 DIN43
34 Not Used -- --
35 Not Used PWM12 DEPOP
2057AA
