207
SJ63 AJ+, SJ63 AJ 229043AAA
Platform Section 5 – Procedures
P13 (White) Slave Controller: SMB1-106
Pin Wire Function Input/Output Type I/O Name Label
1 Not Used Y P30 DOUT19
2 55 Low Fuel Indicator Lamp Y P37 DOUT26
3 577 EcoStart Indicator Light P36 DOUT25
4 27A Tilt Audible Indicator Y P35 DOUT24
5 231 Regen Lamp (EU Stage 5 engine) P34 DOUT23
6 63 SGE Alarm P3B DOUT30
7 82 O/L Lamp P3A DOUT29
8 118 O/L Alarm P39 DOUT28
9 74 Glow Plug Indicator Lamp Y P38 DOUT27
10 119 Load Zone Border Lamp P3F DOUT34
11 120A High capacity zone lamp P3E DOUT33
12 120 Low capacity zone lamp P5C DOUT32
13 27 5 Degree Tilt LED Indicator P31 DOUT20
14 D Drive Controller Y AN16 AIN10
15 Y Main Boom Elevation Controller Y AN17 AIN11
16 X Turret controller Y AN18 AIN12
17 Not Used Y AN19 AIN13
18 Not Used Y AN20 AIN14
19 R Riser Controller (AJ Booms) AN21 AIN15
20 Not Used Y AN22 AIN16
21 Not Used Y AN23 AIN17
22 C Speed control knob (T booms) Y AN25 AIN18
23 76P MIL P3C DOUT31
24 Not Used P32 DOUT21
25 08 Footswitch Indicator Y P33 DOUT22
26 40A Platform Level Down Y PC2 DIN45
27 232 Regen Temp. Override (EU Stage 5 engine) PC5 DIN46
28 35A Platform Rotate Right Y PC8 DIN47
29 36A Platform Rotate Left Y PCA DIN48
30 165A Diff Lock Y PCC DIN49
31 85 Generator On/Off Y PCE DIN50
32 61 SGE - Bar In Y PD0 DIN51
33 62 Reset SGE Y PF4 DIN52
34 Not Used P06 DOUT35
35 165B Diff Lock Indicator P07 DOUT36
2061AA
