Skyjack SJ63 AJ+ Service Manual

60
SJ63 AJ+, SJ63 AJ229043AAA
Section 3 – System Component Identification and Schematics Electrical Component Parts List
Index
No.
Skyjack
Part No.
Description
3H-26 159827 COIL, 12 Volt (Brake valve)
3H-45 159827 COIL, 12 Volt (Motor 2-speed valve)
3H-65 159827 COIL, 12 Volt (Axle lock valve)
3H-165 159827 COIL, 12 Volt (Differential lock valve)
5H-13 159820 COIL, 12 Volt (Boom down valve)
5H-14 159820 COIL, 12 Volt (Boom up valve)
5H-23A 154680 COIL, 12 Volt (Right steer valve)
5H-24A 154680 COIL, 12 Volt (Left steer valve)
5H-30 159820 COIL, 12 Volt (Riser down valve)
5H-31 159820 COIL, 12 Volt (Riser up valve)
5H-32 159819 COIL, 12 Volt (Left turret rotate valve)
5H-33 159819 COIL, 12 Volt (Right turret rotate valve)
5H-34 159819 COIL, 12 Volt (Jib up/Platform left valve)
5H-35 159819 COIL, 12 Volt (Jib down/Platform right valve)
5H-38 159822 COIL, 12 Volt (Boom retract valve)
5H-39 159822 COIL, 12 Volt (Boom extend valve)
5H-40 159819 COIL, 12 Volt (Platform level down valve)
5H-41 159819 COIL, 12 Volt (Platform level up valve)
A1 138224 JOYSTICK (Fly boom/Turret)
A2 138225 JOYSTICK (Drive/Steer)
A3 148707 JOYSTICK (Riser boom)
AT1 149426 ANGLE TRANSDUCER
B1 144676 BATTERY (12V, 950 CCA)
BP1 103057 BEEPER, 4-28 VDC Slow pulsing (Platform control console)
BP2 103056 BEEPER, 7.5-16 VDC (Base control console)
BP3 144387 ALARM, Overload
CAP1 103319 CAPACITOR (50V 1000 uF)
CAP2 103319 CAPACITOR (50V 1000 uF)
CAP3 165411 CAPACITOR (25V 10 000 uF)
CB1 117325 CIRCUIT BREAKER (15 Amp)
CB2 117325 CIRCUIT BREAKER (15 Amp)
CB3 117325 CIRCUIT BREAKER (15 Amp)
CB4 117326 CIRCUIT BREAKER (20 Amp)
CB6 141630 CIRCUIT BREAKER (15 Amp)
CI 152323 INDICATOR, Charge
DXX 102921 DIODE
FU1 138848 FUSE, 50 Amp
FS1 138230 SWITCH, Low fuel
H1 146652 HORN, 12 Volt
LS1 119348 LIMIT SWITCH, Direction sensing
LS2 153856 LIMIT SWITCH, Riser boom down
LS3 153855 LIMIT SWITCH, Main boom down
LS4 153854 LIMIT SWITCH, Fly boom retracted
M1 153800 PUMP, Emergency
PL1 148973 LIGHT, Pilot (Engine fault)
PL2 148972 LIGHT, Pilot (Glow plug)
3.5 Electrical Parts List
