61
SJ63 AJ+, SJ63 AJ 229043AAA
Electrical Component Parts List Section 3 – System Component Identification and Schematics
Index
No.
Skyjack
Part No.
Description
PL3 147229 LED BLOCK, Red (12 volts) (Base control console)
PL4 147229 LED BLOCK, Red (12 volts) (Platform control console)
PL5 138229 MODULE, Upper indicating
PL6 148971 LIGHT, Pilot (Platform control console)
R1 139088 RESISTOR, 6 ohm 25 W
R2 151643 RESISTOR, 250 ohm 1 W
R3 144492 RESISTOR, 680 ohm 1 W (Deutz D2011 & GM engines)
163021 RESISTOR, 120 ohm 1/2 W (Deutz TD2.9L engine)
R4 143952 RESISTOR, 51 ohm 2 W (Deutz D2011 engine)
164855 RESISTOR, 1.0k ohm 1/2 W (Deutz TD2.9L engine)
R5 164856 RESISTOR, 3.3k ohm 1/2 W
R6 164857 RESISTOR, 3.9k ohm 1/2 W
R7 144492 RESISTOR, 680 ohm 1 W
S1 119725 SWITCH, Main power disconnect
S2 138277 KEYSWITCH, Base/Off/Platform (Base control) (ANSI/CSA, AS Deutz D2011)
164949 KEYSWITCH, Base/Off/Platform (Base control) (ANSI/CSA Deutz TD2.9L)
144366 KEYSWITCH, Base/Off/Platform (Base control) (CE)
S3 147053 N.C. CONTACT, Emergency stop (Base control console)
S4 147053 N.C. CONTACT, Emergency stop (Platform control console)
S5 138278 SWITCH, Ignition/emergency pump toggle (Base control console)
S6 138278 SWITCH, Ignition/emergency toggle (Platform control console)
S8 102853 SWITCH, Diagnose toggle (Base control console) (Deutz engine)
S9 124446 SWITCH, Ignition (Platform control console)
S10 115574 SWITCH, Throttle toggle (Platform control console)
S11 138721 ASSEMBLY, Footswitch
S12 138278 SWITCH, Boom up/down toggle (Base control console)
S13 102853 SWITCH, Turret rotate toggle (Base control console)
S14 102853 SWITCH, Telescope in/out toggle (Base control console)
S15 102853 SWITCH, Platform leveling toggle (Base control console)
S16 138278 SWITCH, Platform rotate toggle (Base control console)
S17 102853 SWITCH, Jib up/down toggle (Base control console)
S18 138278 SWITCH, Telescope in/out toggle (Platform control console)
S19 138278 SWITCH, Platform leveling toggle (Platform control console)
S20 138278 SWITCH, Platform rotate toggle (Platform control console)
S21 138278 SWITCH, Jib up/down toggle (Platform control console)
S23 147054 N.O. CONTACT, Horn (Platform control console)
S25 138278 SWITCH, Riser boom up/down toggle (Base control console)
S26 115574 SWITCH, Fuel select (Platform control console) (GM engine)
S28 148998 SWITCH, Differential (Platform control console)
S48 115747 SWITCH, Drive torque toggle (Platform control console)
SMB1-105 218381 MODULE, Master
SMB1-106 218382 MODULE, Slavew
X22 138576 PORT, Diagnose (Deutz engine)
X23 138575 CONNECTOR, Engine (Deutz engine)
3.5 Electrical Parts List
