SPECIFICATIONS
16
Rating
Current
30 A maximum continuous
DUT Protection
Short Circuit current 50 A < 3 s , Inrush Current 180 A Response
time 10 us.
SETTINGS
HI and LO Limit, uA
Range 0-6000 uA, Resolution 1 uA, Hi-Limit 0=OFF
Delay Time, second
Range 0, 1.0-999.9 (0=continuous), Resolution 0.1 s.
Compliance Standards
A UL544NP, UL484, UL923, UL471, UL867, UL697
B IEC60990 Fig4 U2, IEC 60950-1, IEC60335-1,
IEC60598-1, IEC60065, IEC61010
C UL2601-1, IEC60601-1
X External MD(1K Ohm)
F Frequency check, External MD(1K Ohm)
Line Condition
NEUTRAL, REVERSE, GROUND
Probe
G - L
CURRENT MEASURMENT
Frequency Range
DC to 1MHz
Leakage Current Range (RMS)
0uA - 6000uA
Resolution
1uA
Accuracy
DC, 15KHz to 100KHz ±(2% of reading + 3µA)
>100KHz to 1MHz ±5% of reading(100uA-6000uA)
LINE VOLTAGE MEASUREMENT
Range
0.0-277.0 VAC
Resolution
0.1 V
Accuracy
± (1.5% of reading +0.2 V), 60.0-277.0 V
External MD
Basic measuring element 1K Ω
MD A - C,X components
Accuracy: Resistance ± 1% Capacitance ± 5%
MD Voltage Limit
Maximum 30 V peak or 30 VDC
GENERAL SPECIFICATIONS
PLC Remote Control
Input: Test, Reset, Interlock, Recall Memory 1 - 6
Output: Pass, Fail, Test-in-Process
Memory
20 memories, 10 steps per memory
All steps are linkable
Single step mode
Security
Key Lock capability to avoid unauthorized access to all test
parameters. Memory Lock capability to avoid unauthorized
access to memory locations.
Line Cord
Detachable 6 ft (1.8 m) power cable terminated in a three-prong
grounding plug.
Mechanical
Tilt up front feet.
430 mm(W)×133 mm(H)×500 mm(D)/ 22Kg
Environmental
Operating Temperature : 32 - 104F (0 - 40C)
Relative Humidity: 0 to 80%
Calibration
Traceable to National Institute of Standards and Technology
