Slaughter 6330 - Remote Interlock; Interlock Open

OPERATION
62
BIT 3
BIT 2
BIT 1
TEST #
0
0
1
01
0
1
0
02
0
1
1
03
1
0
0
04
1
0
1
05
1
1
0
06
Where: 1 = Momentary Contact closure between BIT and COMMON
0 = NO Contact closure between BIT and COMMON
Activating test program functions through the remote connector
selects the memory and starts the test that is pre-programmed
into that memory.
Do not connect voltage or current to the signal inputs. Applying
voltage to the signal input could result in damage to the control
circuitry.
REMOTE INTERLOCK
The model 6330 is equipped with a featured referred to as “Remote Interlock”. Remote
Interlock is a feature that utilizes a set of closed contacts to enable the instruments output.
In other words, if the Interlock contacts open, the output of the instrument will be
disabled. Remote Interlock could also be referred to as a remote system lockout, utilizing
“Fail When Open” logic. If the Interlock contacts are open and the TEST button is
pushed, a pop-up message will be displayed on the screen for few seconds. The message
will appear as follows:
If the Interlock contacts are opened during a test, the pop-up message will be displayed
and the test will abort.
The hardware and software have been configured to provide the interlock connections on
pins 4 and 5 of the Remote Interface, Signal Input port. This reset scheme is designed for
use with an external safety interlock device that utilizes a "Fail-When-Open"
configuration on its output interface The instrument can still be used without the external
interlock device as long as the Interlock Connector (P/N # 99-10040-01 provided with
unit) is plugged into the Remote Interface, Signal Input port. If there is nothing
connected to the Remote Interface, Signal Input port to provide a connection to the
interlock, the instrument will not perform tests.
Interlock Open
