CALIBRATION
Then press the TEST button on the front panel. The display will show:
Press the Up () or Down () arrow keys to enter the reading of the standard AC
voltmeter into the instrument. Then press SET key to store the current setting and to
advance to the next calibration point or press the RESET button to return to the
calibration menu without changing the calibration setting. Press the EXIT key to exit
from the calibration mode and to return to the test mode.
13. To calibrate the Functional Run test current
Please connect a 30A resistor in series with the standard 30AAC ammeter and connect
these across the DUT Output Power Line and Neutral terminals.
Press the Up () or Down () arrow keys until the display shows:
Then press the TEST button on the front panel and the display will show:
Press the Up () or Down () arrow keys to enter the reading of the standard AC
ammeter into the instrument. Then press SET key to store the current setting and to
advance to the next calibration point or press the RESET button to return to the
calibration menu without changing the calibration setting. Press the EXIT key to exit
from the calibration mode and to return to the test mode
14. To calibrate the Functional Run test power
Please connect a 10Ω resistor in series with the standard power meter’s current inputs.
Connect the power meter’s voltage inputs to the DUT Output Line and Neutral terminals
of the instrument. Connect the AC power supply to the DUT I/P connectors of the
instrument and set the voltage for 225VAC.
Press the Up () or Down () arrow keys until the display shows:
13. RUN 30.0A
L=30Amp,V=120-277VAC
