Slaughter 6330 - Line Leakage Test Mode

OPERATION
56
XXX.Xs
XX-XX XX.XV XX.XA
XXX.Xs
XX-XX XX.XV XX.XA
To stop the alarm, please press the RESET button once. The alarm will stop and the
display will retain the failure information. The instrument is now ready for the next test.
If the RESET button is pressed again, the failure information will be cleared and the
display will indicate the setting data of the test.
4.9. If there is a short circuit in the DUT causing excessive line current during the test,
the red RESET button will illuminate and an alarm will activate. The display will show:
RUN Line-OC XXX.Xs
XX-XX XX.XV XX.XA
To stop the alarm, please press the RESET button once. The alarm will stop and the
display will retain the failure information. The instrument is now ready for the next test.
If the RESET button is pressed again, the failure information will be cleared and the
display will indicate the setting data of the test.
4.10. If there is a short circuit in the DUT causing excessive leakage current during the
test, the red RESET button will illuminate and an alarm will activate. The display will
show:
RUN Leak-OC
XXX.Xs
XX-XX XX.XV XX.XA
To stop the alarm, please press the RESET button once. The alarm will stop and the
display will retain the failure information. The instrument is now ready for the next test.
If the RESET button is pressed again, the failure information will be cleared and the
display will indicate the setting data of the test.
5. Line Leakage test mode
5.1. To initiate a test, press the TEST button on the front panel. The display will
immediately show:
LLT Set XXX.Xs
XX-XX XXX.XV XXXXuA
then
LLT Delay XXX.Xs
XX-XX XXX.XV XXXXuA
The instrument will continue to output the desired voltage for the duration of the selected
Delay time.
5.2. If the DUT has passed the test, the green TEST button will illuminate and a short
audible beep will activate. The display will show:
LLT Pass XXX.Xs
