OPERATION
4.5. If the DUT input current exceeds the high limit setting or does not exceed the low
limit setting, the red RESET button will illuminate and an alarm will activate. The
display will show:
RUN Amp-HI XXX.Xs
XX-XX XX.XV XX.XA
RUN Amp-LO XXX.Xs
XX-XX XX.XV
XX.XA
To stop the alarm, please press the RESET button once. The alarm will stop and the
display will retain the failure information. The instrument is now ready for the next test.
If the RESET button is pressed again, the failure information will be cleared and the
display will indicate the setting data of the test.
4.6. If the DUT input power exceeds the high limit setting or does not exceed the low
limit setting, the red RESET button will illuminate and an alarm will activate. The
display will show:
RUN Power-HI XXX.Xs
XX-XX XX.XV XX.XA
RUN Power-LO XXX.Xs
XX-XX XX.XV XX.XA
To stop the alarm, please press the RESET button once. The alarm will stop and the
display will retain the failure information. The instrument is now ready for the next test.
If the RESET button is pressed again, the failure information will be cleared and the
display will indicate the setting data of the test.
4.7. If the DUT input power factor (PF) exceeds the high limit setting or does not exceed
the low limit setting, the red RESET button will illuminate and an alarm will activate.
The display will show:
RUN PF-HI
XXX.Xs
XXX-X XX.XV XX.XA
RUN PF-LO
XXX.Xs
XX-XX XX.XV XX.XA
To stop the alarm, please press the RESET button once. The alarm will stop and the
display will retain the failure information. The instrument is now ready for the next test.
If the RESET button is pressed again, the failure information will be cleared and the
display will indicate the setting data of the test.
4.8. If the leakage current exceeds the high limit setting, but does not exceed the metering
range, or does not exceed the low limit setting, the red RESET button will illuminate and
an alarm will activate. The display will show:
